LED Linear Highbay Wattage Selectable 15400 – 23100 Lumen (Pack of 2) (OSL-HB)

RESOURCES & DOWNLOADS

(0 Reviews)

$170.00

  • *Wattage & Size

    *CCT

    *Pack

    Reset options

    Motion Sensor (Field Install) (optional)

    25W Emergency Battery Backup (Field Install) (optional)

Details

Brochures & Spec Sheets



   Description

  • LED linear highbay
  • Wattage adjustable
  • 165W(2ft): 110/130/165W adjustable (15,400/18,200/23,100 lumen output) 140lm/w
  • Smooth and comfortable light
  • 100-347V AC Input
  • 0-10V dim
  • Minimum 80 CRI
  • -20°C ~ 40°C operating temperature
  • UL Listed for damp location
  • DLC premium listed
  • 50,000+ hours lifespan
  • 5 years warranty
  • Optional sensor and emergency battery backup available (field installation



   Product Attributes

Brand ONE SOURCE LIGHT
MPN (Part No.) GL-HB5-165W-L
SKU OSL-HB5-165 2-PACK
DLC Part Number GL-HB5-165W-L-5000K
Lighting Technology LED
LED Chip Type
Dimmable Yes
CRI 80+
Color Cool White
Color Temperature 5000 Kelvin
LED L70 Life Hours 50,000
Wattage 110/130/165W
LPW 140
Fixture Type Linear Highbay
Lumens 15,400/18,200/23,100 Lumen Field Selectable
Voltage 100-347V AC Inpu
Ratings and Certifications Damp Location UL / DLC Premium 5.1
Finish White
Mounting Pendant Mount : V-hook and Chain (included)
Surge Protection
Operating Temp -20°C ~ 40°C (-4°F ~ 104°F)
Lens
Length 23.8 in.
Height 2.2 in.
Width 12.6 in.
Package Quantity 2
Weight 8.4 lb. per unit
Warranty 5-Year Limited
